G22 MOSFET Equivalente. Reemplazo. Hoja de especificaciones. Principales características
Número de Parte: G22
Tipo de FET: MOSFET
Polaridad de transistor: N
ESPECIFICACIONES MÁXIMAS
Pdⓘ - Máxima disipación de potencia: 1.25 W
|Vds|ⓘ - Voltaje máximo drenador-fuente: 20 V
|Vgs|ⓘ - Voltaje máximo fuente-puerta: 12 V
|Id|ⓘ - Corriente continua de drenaje: 4.5 A
Tjⓘ - Temperatura máxima de unión: 150 °C
CARACTERÍSTICAS ELÉCTRICAS
trⓘ - Tiempo de subida: 18 nS
Cossⓘ - Capacitancia de salida: 300 pF
RDSonⓘ - Resistencia estado encendido drenaje a fuente: 0.033 Ohm
Encapsulados: SOT23
Búsqueda de reemplazo de G22 MOSFET
- Selecciónⓘ de transistores por parámetros
G22 datasheet
irfpc32 irfpe20 irfpe22 irfpe32 irfpe42 irfpe52 irfpf20 irfpf22 irfpf32 irfpf42 irfpf52 irfpg20 irfpg22 irfpg32 irfpg42 irfpg52.pdf
