SHENZHEN HAOLIN ELECTRONICS TECHNOLOGY CO., LTDSOT-23 Plastic-Encapsulate MOSFET 5N04 N-Channel MOSFET SOT-23ID V(BR)DSS RDS(on)MAX 3m@10V3540V 50 m 5A@4.5Vm@2.5V 601. GATE 12. SOURCE 23. DRAIN FEATURE APPLICATION TrenchFET Power MOSFET Ideal for Load Swith and Battery Low RDS(ON) Protection Applications Typical ESD Protection

HYG015N04LS1C2 Single N-Channel Enhancement Mode MOSFET Feature Description Pin Description 40V/150A D D D D D D D D RDS(ON)= 1.4m (typ.) @VGS = 10V RDS(ON)= 2.0m (typ.) @VGS = 4.5V 100% Avalanche Tested Reliable and Rugged Halogen- Free Devices Available G S S S S S S G Pin1 PDFN5*6-8L Applications Switching Application Power Manageme

HYG025N04NA1C2Single N-Channel Enhancement Mode MOSFETFeature Pin Description 40V/190ARDS(ON)= 1.4m(typ.) @VGS = 10VD D D DD D D D 100% Avalanche Tested Reliable and Rugged Halogen- Free Devices AvailableG S S SS S S GPDFN8L(5x6)Applications Load Switch Lithium battery protect boardSingle N-Channel MOSFETOrdering and Marking InformationPac

JIANGSU CHANGJING ELECTRONICS TECHNOLOGY CO., LTD PDFNWB3.33.3-8L Plastic-Encapsulate MOSFETS CJAB25N04 N-Channel Power MOSFET ID V(BR)DSS RDS(on)MAX PDFNWB3.33.3-8L 9.5m@10V40V25A16m@4.5VDESCRIPTION The CJAB25N04 uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications FEAT

STD95N04STP95N04N-channel 40V - 5.4m - 80A - DPAK - TO-220STripFET Power MOSFETGeneral featuresType VDSS RDS(on) ID PwSTD95N04 40V

Preliminary Data Sheet NP75N04YUK R07DS1004EJ010040 V 75 A N-channel Power MOS FET Rev.1.00Application: Automotive Feb 08, 2013Description The NP75N04YUK is N-channel MOS Field Effect Transistors designed for high current switching applications. Features Super low on-state resistance RDS(on) = 3.3 m MAX. (VGS = 10 V, ID = 38 A) Non logic level drive typ

Preliminary Data Sheet NP75N04YUG R07DS0018EJ0100Rev.1.00MOS FIELD EFFECT TRANSISTOR Jul 01, 2010Description The NP75N04YUG is N-channel MOS Field Effect Transistor designed for high current switching applications. Features Low on-state resistance RDS(on) = 4.8 m MAX. (VGS = 10 V, ID = 37.5 A) Low Ciss: Ciss = 4300 pF TYP. (VDS = 25 V, VGS = 0 V) Designe

To our customers, Old Company Name in Catalogs and Other Documents On April 1st, 2010, NEC Electronics Corporation merged with Renesas Technology Corporation, and Renesas Electronics Corporation took over all the business of both companies. Therefore, although the old company name remains in this document, it is a valid Renesas Electronics document. We appreciate your understanding.

Preliminary Data Sheet NP35N04YUG R07DS0016EJ0100Rev.1.00MOS FIELD EFFECT TRANSISTOR Jul 01, 2010Description The NP35N04YUG is N-channel MOS Field Effect Transistor designed for high current switching applications. Features Low on-state resistance RDS(on) = 10 m MAX. (VGS = 10 V, ID = 17.5 A) Low Ciss: Ciss = 1900 pF TYP. (VDS = 25 V, VGS = 0 V) Designed

Preliminary Data Sheet R07DS0182EJ0100NP35N04YLG Rev.1.00Oct 22, 2010MOS FIELD EFFECT TRANSISTOR Description The NP35N04YLG is N-channel MOS Field Effect Transistor designed for high current switching applications. Features Low on-state resistance RDS(on) = 9.7 m MAX. (VGS = 10 V, ID = 17.5 A) RDS(on) = 15 m MAX. (VGS = 5 V, ID = 17.5 A) Logic level

Preliminary Data Sheet NP75N04VDK R07DS1015EJ010040 V 75 A N-channel Power MOS FET Rev.1.00Application: Automotive Feb 21, 2013Description The NP75N04VDK is N-channel MOS Field Effect Transistors designed for high current switching applications. Features Super low on-state resistance RDS(on) = 5.7 m MAX. (VGS = 10 V, ID = 38 A) Low Ciss: Ciss = 1630 pF

Preliminary Data Sheet NP75N04VUK R07DS0954EJ010040 V 75 A N-channel Power MOS FET Rev.1.00Application: Automotive Nov 20, 2012Description The NP75N04VUK is N-channel MOS Field Effect Transistor designed for high current switching applications. Features Super low on-state resistance RDS(on) = 5.7 m MAX. (VGS = 10 V, ID = 38 A) Low Ciss: Ciss = 1630 pF T

November 2013FDMS015N04BN-Channel PowerTrench MOSFET40 V, 100 A, 1.5 mFeatures Description RDS(on) = 1.13 m (Typ.) @ VGS = 10 V, ID = 50 A This N-Channel MOSFET is produced using Fairchild Advanced Package and Silicon Combination for Low RDS(on) Semiconductors advance PowerTrench process that hasand High Efficiency been tailored to minimize the on-state resistance

SUP/SUB85N04-04Vishay SiliconixN-Channel 40-V (D-S) 175_C MOSFETPRODUCT SUMMARYV(BR)DSS (V) rDS(on) (W) ID (A)40 0.004 @ VGS = 10 V 85 aDTO-220ABTO-263GDRAIN connected to TABG D STop ViewG D SSTop ViewOrdering Information Ordering InformationN-Channel MOSFETSUP85N04-04 SUB85N04-04SUP85N04-04E3 (Lead (Pb)-Free) SUB85N04-04E3 (Lead (Pb)-Free)ABSOLUTE

SUM75N04-05LNew ProductVishay SiliconixN-Channel 40-V (D-S), 175_C MOSFET, Logic LevelFEATURESPRODUCT SUMMARYD TrenchFETr Power MOSFETV(BR)DSS (V) rDS(on) (W) ID (A) Qg (Typ)D 175_C Maximum Junction Temperature0.005 @ VGS = 10 V 75aD 100% Rg Tested40 13040 1300.006 @ VGS = 4.5 V 75aDTO-263GG D STop ViewSOrdering Information: SUM75N04-05L E3N-Channel

SUP/SUB85N04-03New ProductVishay SiliconixN-Channel 40-V (D-S) 175_C MOSFETPRODUCT SUMMARYV(BR)DSS (V) rDS(on) (W) ID (A)0.0035 @ VGS = 10 Va40 85 a40 850.0053 @ VGS = 4.5 VDTO-220ABTO-263GDRAIN connected to TABG D STop ViewG D SSSUB85N04-03Top ViewN-Channel MOSFETSUP85N04-03ABSOLUTE MAXIMUM RATINGS (TC = 25_C UNLESS OTHERWISE NOTED)Parameter Sy

SUP/SUB75N04-05LVishay SiliconixN-Channel 40-V (D-S), 175_C MOSFET, Logic LevelPRODUCT SUMMARYV(BR)DSS (V) rDS(on) (W) ID (A)0.0055 @ VGS = 10 V 75a400.0065 @ VGS = 4.5 V 75aDTO-220ABTO-263GDRAIN connected to TABG D STop ViewG D SSSUB75N04-05LTop ViewN-Channel MOSFETSUP75N04-05LABSOLUTE MAXIMUM RATINGS (TC = 25_C UNLESS OTHERWISE NOTED)Parameter Symbo

SUP/SUB85N04-03New ProductVishay SiliconixN-Channel 40-V (D-S) 175_C MOSFETPRODUCT SUMMARYV(BR)DSS (V) rDS(on) (W) ID (A)0.0035 @ VGS = 10 Va40 85 a40 850.0053 @ VGS = 4.5 VDTO-220ABTO-263GDRAIN connected to TABG D STop ViewG D SSSUB85N04-03Top ViewN-Channel MOSFETSUP85N04-03ABSOLUTE MAXIMUM RATINGS (TC = 25_C UNLESS OTHERWISE NOTED)Parameter Sy

SUD25N04-25Vishay SiliconixN-Channel 40-V (D-S) 175_C MOSFETPRODUCT SUMMARYVDS (V) rDS(on) (W) ID (A)0.025 @ VGS = 10 V 25400.040 @ VGS = 4.5 V 20DTO-252GDrain Connected to TabG D STop ViewOrder Number:SSUD25N04-25N-Channel MOSFETABSOLUTE MAXIMUM RATINGS (TA = 25_C UNLESS OTHERWISE NOTED)Parameter Symbol Limit UnitDrain-Source Voltage VDS 40VGate-Sour

pe % # ! % (>.;?6?@%>EFeaturesV 4 D Q 2CD CG:D49:?8 ') - . 7@B -'*-R 1 m D n) m xQ ) AD:>:J65 D649?@=@8I 7@B 4@?F6BD6BCI 4 D1)Q + E2=:7:65 244@B5:?8 D@ $ 7@B D2B86D 2AA=:42D:@?CQ ( 492??6= =@8:4 =6F6=Q H46==6?D 82D6 492B86 H R AB@5E4D ) ' D n)Q /6BI =@G @? B6C:CD2?46 RD n)Q F2=2?496 D6CD65Q *3 7B66 A=2D:?8 , @"- 4@>A=:2?DType #

IAUC100N08S5N043OptiMOS-5 Power-TransistorProduct SummaryVDS 80 VRDS(on) 4.3mWID 100 AFeatures N-channel - Enhancement modePG-TDSON-8 AEC Q101 qualified MSL1 up to 260C peak reflow 175C operating temperature Green product (RoHS compliant) 1 100% Avalanche tested1Type Package MarkingPG-TDSON-8 5N08043IAUC100N08S5N043Maximum ratings,

pe ## ! ! # ! ! D #:A0;53E;A@DR ' 5:3@@7> @AC?3> >7G7>R I57>>7@E 93E7 5:3C97 I BCA6F5E ( & D n)R .7CJ >AH A@ C7D;DE3@57 D n)R G3>3@5:7 E7DE76R )4 8C77 B>3E;@9 + A", 5A?B>;3@ER "

pe $ " E $;B1= '=-:>5>?;=$=;0@/? &@99-=DFeatures 4 D S 4EF EI

pe ## ! ! # ! ! D #:A0;53E;A@DR ' 5:3@@7> @AC?3> >7G7>R I57>>7@E 93E7 5:3C97 I BCA6F5E ( & D n)R .7CJ >AH A@ C7D;DE3@57 D n)R G3>3@5:7 E7DE76R )4 8C77 B>3E;@9 + A", 5A?B>;3@ER "

pe ## ! ! # ! ! D #:A0;53E;A@DR ' 5:3@@7> @AC?3> >7G7>R I57>>7@E 93E7 5:3C97 I BCA6F5E ( & D n)R .7CJ >AH A@ C7D;DE3@57 D n)R G3>3@5:7 E7DE76R )4 8C77 B>3E;@9 + A", 5A?B>;3@ER "

pe $ " E $;B1= '=-:>5>?;=$=;0@/? &@99-=DFeatures 4 D S 4EF EI

n-Channel Power MOSFETOptiMOSBSB015N04NX3 G Data Sheet2.3, 2011-05-24Final Industrial & MultimarketOptiMOS Power-MOSFETBSB015N04NX3 G1 DescriptionOptiMOS40V products are class leading power MOSFETs for highest powerdensity and energy efficient solutions. Ultra low gate- and output charges togetherwith lowest on state resistance in small footprint packages make

MOSFETMetal Oxide Semiconductor Field Effect TransistorOptiMOSTMOptiMOSTM Power-MOSFET, 40 VBSZ025N04LSData SheetRev. 2.1FinalPower Management & MultimarketOptiMOSTM Power-MOSFET, 40 VBSZ025N04LSTSDSON-8 FL1 Description(enlarged source interconnection)Features Optimized for synchronous rectification Very low on-resistance RDS(on) 100% avalanche test

IPD75N04S4-06OptiMOS-T2 Power-TransistorProduct SummaryV 40 VDSR 5.9mDS(on),maxI 75 ADFeatures N-channel - Enhancement modePG-TO252-3-313 AEC qualified MSL1 up to 260C peak reflow 175C operating temperature Green Product (RoHS compliant) 100% Avalanche testedType Package MarkingIPD75N04S4-06 PG-TO252-3-313 4N0406Maximum ratings,

pe $$ " " $;B1= '=-:>5>?;=$=;0@/? &@99-=DFeatures 4 D R 3DE DH;E5:;@9 &( , - 8AC ,&), m , A@ ?3I R ( BE;?;K76 E75:@A>A9J 8AC 5A@G7CE7CDD1)R * F3>;8;76 355AC6;@9 EA $ 8AC E3C97E 3BB>;53E;A@DR ' 5:3@@7> @AC?3> >7G7>R I57>>7@E 93E7 5:3C97 I BCA6F5E ( & D n)R .7CJ >AH A@ C7D;DE3@57 D n)R G3>3@5:7 E7DE76R )4 8C77 B>3E;@9 + A", 5A?B>;3@EType #)) ' ' !

$) $ D ":A 0

IAUC100N10S5N040OptiMOSTM-5 Power-TransistorProduct SummaryVDS 100 VRDS(on) 4mID 100 AFeatures N-channel - Enhancement mode - Normal levelPG-TDSON-8 AEC qualified MSL1 up to 260C peak reflow 100% Avalanche tested Feasible for automatic optical inspection (AOI)1Type Package MarkingIAUC100N10S5N040 PG-TDSON-8 5N1N040Maximum ratings, at T =25

BSC035N04LS GOptiMOS3 Power-TransistorProduct SummaryFeaturesV 40 VDS Fast switching MOSFET for SMPSR 3.5mDS(on),max Optimized technology for DC/DC convertersI 100 AD Qualified according to JEDEC1) for target applicationsPG-TDSON-8 N-channel; Logic level Excellent gate charge x R product (FOM)DS(on) Very low on-resistance RDS(on)

pe % # ! % (>.;?6?@%>EFeatures 4 D Q 2CD CG:D49:?8 ') - . 7@B -'*- 7 m D n) m xQ ) AD:>:J65 D649?@=@8I 7@B 4@?F6BD6BCD1)Q + E2=:7:65 244@B5:?8 D@ $ 7@B D2B86D 2AA=:42D:@?CQ ( 492??6= =@8:4 =6F6=Q H46==6?D 82D6 492B86 H AB@5E4D ) ' D n)Q /6BI =@G @? B6C:CD2?46 G O D n)Q F2=2?496 D6CD65Q *3 7B66 A=2D:?8 , @"- 4@>A=:2?DQ "2=@86?

IPB45N04S4L-08IPI45N04S4L-08, IPP45N04S4L-08OptiMOS-T2 Power-TransistorProduct SummaryV 40 VDSR (SMD version) 7.6mDS(on),max I 45 ADFeaturesPG-TO263-3-2 PG-TO262-3-1 PG-TO220-3-1 N-channel - Enhancement mode AEC qualified MSL1 up to 260C peak reflow 175C operating temperature Green Product (RoHS compliant) 100% Avalanche testedTyp

$) $ D ":A 0

NVBLS0D5N04M8MOSFET Power, Single,N-Channel40 V, 300 A, 0.57 mWFeatureswww.onsemi.com Typical RDS(on) = 0.46 mW at VGS = 10 V, ID = 80 A Typical Qg(tot) = 220 nC at VGS = 10 V, ID = 80 A UIS Capability AEC-Q101 Qualified and PPAP Capable These Devices are Pb-Free and are RoHS CompliantMAXIMUM RATINGS TJ = 25C unless otherwise notedMO-299AParameter

NTTFS005N04CPower MOSFET40 V, 5.6 mW, 69 A, Single N-ChannelFeatures Small Footprint (3.3 x 3.3 mm) for Compact Design Low RDS(on) to Minimize Conduction Losseswww.onsemi.com Low Capacitance to Minimize Driver Losses These Devices are Pb-Free and are RoHS CompliantV(BR)DSS RDS(on) MAX ID MAXMAXIMUM RATINGS (TJ = 25C unless otherwise noted)Parameter Symbol Val

NVTFS015N04CMOSFET Power, SingleN-Channel40 V, 17.3 mW, 27 AFeatureswww.onsemi.com Small Footprint (3.3 x 3.3 mm) for Compact Design Low RDS(on) to Minimize Conduction Losses Low Capacitance to Minimize Driver Losses NVTFWS015N04C - Wettable Flanks Product V(BR)DSS RDS(on) MAX ID MAX AEC-Q101 Qualified and PPAP Capable40 V 17.3 mW @ 10 V 27 A These

Is Now Part ofTo learn more about ON Semiconductor, please visit our website at www.onsemi.comPlease note: As part of the Fairchild Semiconductor integration, some of the Fairchild orderable part numbers will need to change in order to meet ON Semiconductors system requirements. Since the ON Semiconductor product management systems do not have the ability to manage part nomenclatur

NJD35N04G,NJVNJD35N04G,NJVNJD35N04T4GNPN Darlington PowerTransistorhttp://onsemi.comThis high voltage power Darlington has been specifically designedfor inductive applications such as Electronic Ignition, SwitchingRegulators and Motor Control.DARLINGTONFeaturesPOWER TRANSISTORS Exceptional Safe Operating Area4 AMPERES High VCE; High Current Gain350 VOLTS

NTTFS015N04CMOSFET Power, Single,N-Channel40 V, 17.3 mW, 27 AFeatureswww.onsemi.com Small Footprint (3.3 x 3.3 mm) for Compact Design Low RDS(on) to Minimize Conduction Losses Low Capacitance to Minimize Driver Losses These Devices are Pb-Free and are RoHS Compliant V(BR)DSS RDS(on) MAX ID MAX40 V 17.3 mW @ 10 V 27 AMAXIMUM RATINGS (TJ = 25C unless otherw

NVTFS005N04CPower MOSFET40 V, 5.6 mW, 69 A, Single N-ChannelFeatures Small Footprint (3.3 x 3.3 mm) for Compact Design Low RDS(on) to Minimize Conduction Losseswww.onsemi.com Low Capacitance to Minimize Driver Losses NVTFWS005N04C - Wettable Flanks Product AEC-Q101 Qualified and PPAP CapableV(BR)DSS RDS(on) MAX ID MAX These Devices are Pb-Free and are RoH

NJD35N04G,NJVNJD35N04G,NJVNJD35N04T4GNPN Darlington PowerTransistorhttp://onsemi.comThis high voltage power Darlington has been specifically designedfor inductive applications such as Electronic Ignition, SwitchingRegulators and Motor Control.DARLINGTONFeaturesPOWER TRANSISTORS Exceptional Safe Operating Area4 AMPERES High VCE; High Current Gain350 VOLTS

NJD35N04G,NJVNJD35N04G,NJVNJD35N04T4GNPN Darlington PowerTransistorhttp://onsemi.comThis high voltage power Darlington has been specifically designedfor inductive applications such as Electronic Ignition, SwitchingRegulators and Motor Control.DARLINGTONFeaturesPOWER TRANSISTORS Exceptional Safe Operating Area4 AMPERES High VCE; High Current Gain350 VOLTS

JIANGSU CHANGJING ELECTRONICS TECHNOLOGY CO., LTD PDFNWB3.33.3-8L Plastic-Encapsulate MOSFETS CJAB25N04 N-Channel Power MOSFET ID V(BR)DSS RDS(on)MAX PDFNWB3.33.3-8L 9.5m@10V40V25A16m@4.5VDESCRIPTION The CJAB25N04 uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications FEAT

Spec. No. : C884J3 Issued Date : 2012.12.07 CYStech Electronics Corp.Revised Date : 2014.03.14 Page No. : 1/9 N -Channel Enhancement Mode Power MOSFET BVDSS 40VMTB25N04J3 ID 29ARDS(ON)@VGS=10V, ID=12A 20m(typ) RDS(ON)@VGS=4.5V, ID=10A 27m(typ) Features Low Gate Charge Simple Drive Requirement Pb-free lead plating and halogen-free package Equivalen

Spec. No. : C453J3 Issued Date : 2009.03.11 CYStech Electronics Corp.Revised Date : Page No. : 1/7 N -Channel Enhancement Mode Power MOSFET BVDSS 40VMTB35N04J3 ID 12A35m RDSON(MAX) Features Low Gate Charge Simple Drive Requirement RoHS compliant & Halogen-free package Equivalent Circuit Outline MTB35N04J3 TO-252 G D S GGate DDrain SS

GreenProductSDU/D05N04aS mHop Microelectronics C orp.Ver 1.2N-Channel Enhancement Mode Field Effect TransistorFEATURESPRODUCT SUMMARYSuper high dense cell design for low RDS(ON).VDSS ID RDS(ON) () TypRugged and reliable.400V 4A 2.1 @ VGS=10V Suface Mount Package.DGSSDU SERIES SDD SERIES SDD SERIESTO-252(D-PAK) TO-251S(I-PAK) TO-251L(I-PAK)ORDERING INFORMATI

BRCS025N04DP Rev.A Jul.-2022 DATA SHEET / Descriptions TO-252 N N-CHANNEL MOSFET in a TO-252 Plastic Package. / Features R C DS(on) rssLow RDS(on),low gate charge, low Crss, fast switching, HF Product. / Applications DC/D

BRCS035N04SDP Rev.A Mar.-2023 DATA SHEET / Descriptions TO-252 N N-CHANNEL MOSFET in a TO-252 Plastic Package. / Features R C DS(on) rssLow R ,low gate charge, low C , fast switching, HF Product. DS(on) rss / Applications

BRCS015N04SZC Rev.B Feb.-2023 DATA SHEET / Descriptions PDFN56 N N-Channel MOSFET in a PDFN56 Plastic Package. / Features Low R to minimize conductive loss;low Gate Charge for fast switching;Low Thermal resistance; DS(ON

DH035N04/DHF035N04/DHI035N04/DHE035N04/DHB035N04/DHD035N04155A 40V N-channel Enhancement Mode Power MOSFET1 DescriptionThese N-channel enhanced vdmosfets used advanced2 DV = 40VDSStrench technology design, provided excellent Rdson andlow gate charge. Which accords with the RoHS standard.R = 2.3mDS(on) (TYP)G12 Features I = 155AD3 S Fast switching High

DHP035N04140A 40V N-channel Enhancement Mode Power MOSFET1 DescriptionThese N-channel enhanced vdmosfets used advanced2 DV = 40VDSStrench technology design, provided excellent Rdson andlow gate charge. Which accords with the RoHS standard.R = 2.3mDS(on) (TYP)G12 Features I = 140AD3 S Fast switching High avalanche Current Low on resistance(Rdson3

DH065N04P60A 40V N-channel Enhancement Mode Power MOSFET1 DescriptionThe N-channel enhancement mode power mosfets used2 DV = 40VDSSadvanced trench technology design, provided excellentRdson and low gate charge. Which accords with the RoHSGR = 6.3mDS(on) (TYP)standard.13 SI = 60AD2 Features Low on resistance Low gate charge Fast switching L

DSD065N04LA40V/5.5m/82A N-MOSFETFeatures Key Parameters AEC-Q101 qualified VDS 40V Low on resistance RDS(on)typ. 5.5m Low reverse transfer capacitances ID 82A 100% single pulse avalanche energy test VTH 1.7V 100% VDS test Ciss@10V 901pF Pb-Free plating / Halogen-Free / RoHS compliant Qgd 1nCApplications Motor Control and Drive Charge/Discharge

DH065N04/DH065N04FDH065N04I/DH065N04E/DH065N04B/DH065N04D80A 40V N-channel Enhancement Mode Power MOSFET1 DescriptionThese N-channel enhancement mode power mosfets used2 DV = 40VDSSadvanced trench technology design, provided excellentRdson and low gate charge. Which accords with the RoHSGR = 6.0mDS(on) (TYP)standard.13 SI = 80AD2 Features Low on resist

DTG045N04NA&DTE043N04NA120A 40V N-channel Enhancement Mode Power MOSFET1 DescriptionThese N-channel enhancement mode power mosfets used2 DV = 40VDSSadvanced trench technology design, provided excellentRdson and low gate charge. Which accords with the RoHSR = 3.8mTo-220DS(on) (TYP)Gstandard.1R = 3.6mTo-263DS(on) (TYP)3 S2 FeaturesI = 120AD

DH025N04/DH025N04F/DH025N04IDH025N04E/DH025N04B/DH025N04D130A 40V N-channel Enhancement Mode Power MOSFET1 DescriptionThese N-channel enhancement mode power mosfets used2 DV = 40VDSSadvanced trench technology design, provided excellentRdson and low gate charge. Which accords with the RoHSGR = 2.8mDS(on) (TYP)standard.13 SI = 130AD2 Features Low on resi

DH045N04/DH045N04FDH045N04I/DH045N04E/DH045N04B/DH045N04D90A 40V N-channel Enhancement Mode Power MOSFET1 DescriptionThese N-channel enhancement mode power mosfets used2 DV = 40VDSSadvanced trench technology design, provided excellentRdson and low gate charge. Which accords with the RoHSGR = 5.5mDS(on) (TYP)standard.13 SI = 90AD2 Features Low on resist

DTE025N04NA&DTG025N04NA220A 40V N-channel Enhancement Mode Power MOSFET1 DescriptionThese N-channel enhancement mode power mosfets used2 DV = 40VDSSadvanced trench technology design, provided excellentRdson and low gate charge. Which accords with the RoHSGR = 2.1mDS(on) (TYP)standard.13 SI = 220AD2 Features AEC Q101 qualified MSL1 up to 260C peak

DH045N04P80A 40V N-channel Enhancement Mode Power MOSFET1 DescriptionThese N-channel enhancement mode power mosfets used2 DV = 40VDSSadvanced trench technology design, provided excellentRdson and low gate charge. Which accords with the RoHSGR = 5.7mDS(on) (TYP)standard.13 SI = 80AD2 Features Low on resistance Low gate charge Fast switching

BLM055N04 Power MOSFET 1Description Step-Down Converter The BLM055N04 uses advanced trench , technology to provide excellent RDS(ON), low gate charge. It can be used in a wide variety of applications. KEY CHARACTERISTICS Parameter Value Unit V 40 V DSI 80 A DR .Typ 3.4 m DS(ON)@10V R .Typ 4.5 m DS(ON)@4.5V FEATURES Advanced Trench Technolog

BLM075N04 Power MOSFET 1Description Step-Down Converter The BLM075N04 uses advanced trench , technology to provide excellent RDS(ON), low gate charge. It can be used in a wide variety of applications. KEY CHARACTERISTICS Parameter Value Unit V 40 V DSI 60 A DR .Typ 5.4 m DS(ON)@10V R .Typ 7.8 m DS(ON)@4.5V FEATURES Advanced Trench Technolog

SW15N04V N-channel Enhanced mode SOP8/DFN5*6 MOSFET Features BVDSS : 40V DFN5*6 SOP8 5 ID : 15A High ruggedness 6 1 8 7 Low RDS(ON) (Typ 6.5m)@VGS=4.5V 2 7 8 RDS(ON) : 6.5m@ VGS=4.5V 6 3 (Typ 5.8m)@VGS=10V 4 3 4 5 5.8m @ VGS=10V Low Gate Charge (Typ 49nC) 2 1 Improved dv/dt Capability D 100% Avalanche Tested

December 2014 BVDSS = 40 V RDS(on) typ = 2.9m HRP35N04K ID = 150 A 40V N-Channel Trench MOSFET TO-220 FEATURES Originative New Design Superior Avalanche Rugged Technology 1 2 3 Excellent Switching Characteristics 1.Gate 2. Drain 3. Source Unrivalled Gate Charge : 110 nC (Typ.) Extended Safe Operating Area Lower RDS(ON) : 2.9 m (Typ.

WMO75N04T1 40V N-Channel Enhancement Mode Power MOSFET DescriptionWMO75N04T1 uses advanced power trench technology that has been especially tailored to minimize the on-state resistance and yet maintain superior switching performance. DFeatures SG V = 40V, I = 75A DS DTO-252R

WMQ55N04T1 40V N-Channel Enhancement Mode Power MOSFET DescriptionDDDWMQ55N04T1 uses advanced power trench technology that has DDDD Dbeen especially tailored to minimize the on-state resistance and yet maintain superior switching performance. SGSSSSGSFeatures PDFN3030-8L V = 40V, I = 55A DS DR

HTN035N04P P-140V N-Ch Power MOSFET40 VFeature VDS3.2 Optimized for high speed switching RDS(on),typ VGS=10V mW7.4RDS(on),typ VGS=6V mW Enhanced Body diode dv/dt capability95 AID (Sillicon Limited) Enhanced Avalanche Ruggedness 100% UIS Tested, 100% Rg Tested Lead Free, Halogen FreeApplication Synchronous Rectification in SMPSDrain Hard Swi

RoHS COMPLIANT YJQ35N04A N-Channel Enhancement Mode Field Effect Transistor Product Summary V 40 V DS I 35 A D R ( at V = 10V) 8.0mohm DS(ON) GS R ( at V = 4.5V) 13mohm DS(ON) GS 100% UIS Tested 100% VDS Tested General Description Trench Power LV MOSFET technology Excellent package for heat dissipation High density c

TTD65N04AT Wuxi Unigroup Microelectronics CO.,LTD. 40V N-Channel Trench MOSFET(Preliminary) General Description Product Summary Trench Power technology VDS 40V Low RDS(ON) ID (at VGS =10V) 65A Low Gate Charge RDS(ON) (at VGS =10V)

S85N048S SI-TECH SEMICONDUCTOR CO.,LTD N-Channel Power MOSFET Features Applications VDS=85V,ID=120A DC Motor Control Rds(on)(typ)=4.8m@Vgs=10V DC-DC Converters 100% Avalanche Tested BMS 100% Rg TestedSMPSLead-Free (RoHS Compliant) Automotive Environment Internal Circuit and Pin Description D DG G

S85N042R/S/RN/RP SI-TECH SEMICONDUCTOR CO.,LTD N-Channel Power MOSFET Features Applications VDS=85V,ID=128A DC Motor Control Rds(on)(typ)=4.2m@Vgs=10V DC-DC Converters 100% Avalanche Tested BMS 100% Rg Tested SMPS Lead-Free (RoHS Compliant) Automotive Environment Internal Circuit and Pin Description D D G G G G G D D

INCHANGE Semiconductorisc N-Channel MOSFET Transistor IPB015N04LFEATURESWith TO-263( D2PAK ) packagingHigh speed switchingLow gate input resistanceStandard level gate driveEasy to use100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSPower supplySwitching applicationsABSOLUTE MAXIM

Isc N-Channel MOSFET Transistor IPB015N04NFEATURESWith To-263(D2PAK) packageLow input capacitance and gate chargeLow gate input resistance100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSSwitching applicationsABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Vo

INCHANGE Semiconductorisc N-Channel MOSFET Transistor IPP015N04NIIPP015N04NFEATURESStatic drain-source on-resistance:RDS(on) 1.5mEnhancement modeFast Switching Speed100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationDESCRITIONreliable device for use in a wide variety of applicationsABSOLUTE MAX
