SL150N03Q MOSFET Equivalente. Reemplazo. Hoja de especificaciones. Principales características

Número de Parte: SL150N03Q

Tipo de FET: MOSFET

Polaridad de transistor: N

ESPECIFICACIONES MÁXIMAS

Pdⓘ - Máxima disipación de potencia: 166 W

|Vds|ⓘ - Voltaje máximo drenador-fuente: 30 V

|Vgs|ⓘ - Voltaje máximo fuente-puerta: 20 V

|Id|ⓘ - Corriente continua de drenaje: 150 A

Tjⓘ - Temperatura máxima de unión: 175 °C

CARACTERÍSTICAS ELÉCTRICAS

trⓘ - Tiempo de subida: 45 nS

Cossⓘ - Capacitancia de salida: 945 pF

RDSonⓘ - Resistencia estado encendido drenaje a fuente: 0.0016 Ohm

Encapsulados: DFN5X6-8L

 Búsqueda de reemplazo de SL150N03Q MOSFET

- Selecciónⓘ de transistores por parámetros



SL150N03Q datasheet

 ..1. Size:1148K  slkor
 sl150n03q.pdf pdf_icon

SL150N03Q

SL150N03Q N-Channel Power MOSFET General Features VDS =30V,ID =150A RDS(ON)
