AP5N15MSI MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características


   Número de Parte: AP5N15MSI
   Tipo de FET: MOSFET
   Polaridad de transistor: N

ESPECIFICACIONES MÁXIMAS

   Pdⓘ - Máxima disipación de potencia: 2 W
   |Vds|ⓘ - Voltaje máximo drenador - fuente: 150 V
   |Vgs|ⓘ - Voltaje máximo fuente - puerta: 20 V
   |Id|ⓘ - Corriente continua de drenaje: 3 A
   Tjⓘ - Temperatura máxima de unión: 150 °C

CARACTERÍSTICAS ELÉCTRICAS


   trⓘ - Tiempo de subida: 9.3 nS
   Cossⓘ - Capacitancia de salida: 55 pF
   Rds(on)ⓘ - Resistencia estado encendido drenaje a fuente: 0.32 Ohm
   Paquete / Cubierta: SOT223


 Búsqueda de reemplazo de AP5N15MSI MOSFET

   - Selección ⓘ de transistores por parámetros



AP5N15MSI Datasheet (PDF)

 ..1. Size:1255K  cn apm
 ap5n15msi.pdf pdf_icon

AP5N15MSI

AP5N15MSI 150V N-Channel Enhancement Mode MOSFET Description The AP5N15MSI uses advanced trench technology to provide excellent R , low gate charge and DS(ON)operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 150V I =5A DS D R

 9.1. Size:1712K  cn apm
 ap5n10mi.pdf pdf_icon

AP5N15MSI

AP5N10MI 100V N-Channel Enhancement Mode MOSFET Description The AP5N10MI uses advanced trench technology to provide excellent R , low gate charge and DS(ON)operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 100V I =5A DS DR

 9.2. Size:1620K  cn apm
 ap5n10si.pdf pdf_icon

AP5N15MSI

AP5N10SI 100V N-Channel Enhancement Mode MOSFET Description The AP5N10SI uses advanced trench technology to provide excellent R , low gate charge and DS(ON)operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 100V I =5A DS DR

 9.3. Size:1018K  cn apm
 ap5n10bi.pdf pdf_icon

AP5N15MSI

AP5N10BI100V N-Channel Enhancement Mode MOSFETDescriptionThe AP5N10BI uses advanced APM-SGTII technologyto provide excellent R , low gate charge andDS(ON)operation with gate voltages as low as 4.5V. Thisdevice is suitable for use as a Battery protectionor in other Switching application.General FeaturesV = 100V I =5.0ADS DR
