P27 Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características
Número de Parte: P27 📄📄
Material: Ge
Polaridad de transistor: PNP
ESPECIFICACIONES MÁXIMAS
Disipación total del dispositivo (Pc): 0.03 W
Tensión colector-base (Vcb): 5 V
Corriente del colector DC máxima (Ic): 0.006 A
Temperatura operativa máxima (Tj): 75 °C
CARACTERÍSTICAS ELÉCTRICAS
Transición de frecuencia (fT): 1 MHz
Capacitancia de salida (Cc): 50 pF
Ganancia de corriente contínua (hFE): 20
