2SA16 Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características
Número de Parte: 2SA16 📄📄
Material: Ge
Polaridad de transistor: PNP
ESPECIFICACIONES MÁXIMAS
Disipación total del dispositivo (Pc): 0.08 W
Tensión colector-base (Vcb): 12 V
Tensión emisor-base (Veb): 1 V
Corriente del colector DC máxima (Ic): 0.01 A
Temperatura operativa máxima (Tj): 75 °C
CARACTERÍSTICAS ELÉCTRICAS
Transición de frecuencia (fT): 5 MHz
Capacitancia de salida (Cc): 13 pF
Ganancia de corriente contínua (hFE): 60
Encapsulados: TO1
📄📄 Copiar
