Type Designator: 2N65

Type of Transistor: MOSFET

Type of Control Channel: N -Channel

Maximum Power Dissipation (Pd): 40 W

Maximum Drain-Source Voltage |Vds|: 650 V

Maximum Gate-Source Voltage |Vgs|: 30 V

Maximum Drain Current |Id|: 2 A

Maximum Junction Temperature (Tj): 150 °C

Rise Time (tr): 40 nS

Drain-Source Capacitance (Cd): 40 pF

Maximum Drain-Source On-State Resistance (Rds): 3.9 Ohm

Package: TO-220_TO-262_TO-126_TO-251_TO-252_TO-220F

2N65 Transistor Equivalent Substitute - MOSFET Cross-Reference Search
