DMD4523D Spec and Replacement


   Type Designator: DMD4523D
   Type of Transistor: MOSFET
   Type of Control Channel: N -Channel
   Pd ⓘ - Maximum Power Dissipation: 89 W
   |Vds|ⓘ - Maximum Drain-Source Voltage: 450 V
   |Vgs|ⓘ - Maximum Gate-Source Voltage: 20 V
   |Id| ⓘ - Maximum Drain Current: 2.5 A
   Tj ⓘ - Maximum Junction Temperature: 150 °C
   tr ⓘ - Rise Time: 150 nS
   Cossⓘ - Output Capacitance: 47 pF
   Rds ⓘ - Maximum Drain-Source On-State Resistance: 2.2 Ohm
   Package: TO252

 DMD4523D Transistor Equivalent Substitute - MOSFET Cross-Reference Search



DMD4523D Specs

 ..1. Size:702K  ark-micro
 dmu4523d dmd4523d dma4523d.pdf pdf_icon

DMD4523D

DMU4523D/DMD4523D/DMA4523D Depletion-Mode Power MOSFET General Features Depletion Mode (Normally On) BVDSX RDS(ON) (Max.) IDSS,min Proprietary Advanced Planar Technology Rugged Polysilicon Gate Cell Structure 450V 2.2 2A Fast Switching Speed RoHS Compliant Halogen-free available D Applications Suppressing surge current Normally-on ... See More ⇒
