   Type Designator: P75N02LDG
   Type of Transistor: MOSFET
   Type of Control Channel: N -Channel
   Pdⓘ - Maximum Power Dissipation: 54 W
   |Vds|ⓘ - Maximum Drain-Source Voltage: 25 V
   |Vgs|ⓘ - Maximum Gate-Source Voltage: 20 V
   |Id|ⓘ - Maximum Drain Current: 75 A
   Tjⓘ - Maximum Junction Temperature: 150 °C
   trⓘ - Rise Time: 17 nS
   Cossⓘ - Output Capacitance: 712 pF
   Rdsⓘ - Maximum Drain-Source On-State Resistance: 0.007 Ohm
   Package: TO252

 P75N02LDG Transistor Equivalent Substitute - MOSFET Cross-Reference Search



P75N02LDG Datasheet (PDF)

 ..1. Size:613K  unikc
p75n02ldg.pdf

P75N02LDG P75N02LDG

P75N02LDGN-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID5m @VGS = 10V25V 75ATO-252ABSOLUTE MAXIMUM RATINGS (TC = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVGSGate-Source Voltage 20 VTC = 25 C75IDContinuous Drain CurrentTC = 100 C50AIDM170Pulsed Drain Current1IASAvalanche Current 45E
