AP50PN520R MOSFET. Datasheet pdf. Equivalent
Type Designator: AP50PN520R
Type of Transistor: MOSFET
Type of Control Channel: N -Channel
Pdⓘ - Maximum Power Dissipation: 138.8 W
|Vds|ⓘ - Maximum Drain-Source Voltage: 500 V
|Vgs|ⓘ - Maximum Gate-Source Voltage: 20 V
|Id|ⓘ - Maximum Drain Current: 12 A
Tjⓘ - Maximum Junction Temperature: 150 °C
trⓘ - Rise Time: 15 nS
Cossⓘ - Output Capacitance: 70 pF
Rdsⓘ - Maximum Drain-Source On-State Resistance: 0.52 Ohm
Package: TO262
AP50PN520R Transistor Equivalent Substitute - MOSFET Cross-Reference Search
AP50PN520R Datasheet (PDF)
ap50pn520r.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AP50PN520RHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test BVDSS 500VD Fast Switching Characteristic RDS(ON) 0.52 Simple Drive Requirement ID 12AG RoHS Compliant & Halogen-FreeSDescriptionAP50PN520 series are from Advanced Power innovated design andsilicon process technology to achieve the lowe
