AP1003BST Datasheet. Specs and Replacement
Type Designator: AP1003BST 📄📄
Type of Transistor: MOSFET
Type of Control Channel: N-Channel
Absolute Maximum Ratings
Pd ⓘ - Maximum Power Dissipation: 2.2 W
|Vds|ⓘ - Maximum Drain-Source Voltage: 30 V
|Vgs|ⓘ - Maximum Gate-Source Voltage: 20 V
|Id| ⓘ - Maximum Drain Current: 17.3 A
Tj ⓘ - Maximum Junction Temperature: 150 °C
Electrical Characteristics
tr ⓘ - Rise Time: 41 nS
Cossⓘ - Output Capacitance: 400 pF
RDSonⓘ - Maximum Drain-Source On-State Resistance: 0.0047 Ohm
Package: CHIP
📄📄 Copy
- MOSFET ⓘ Cross-Reference Search
AP1003BST datasheet
..1. Size:158K ape
ap1003bst.pdf
AP1003BST Preliminary Advanced Power N-CHANNEL ENHANCEMENT MODE Electronics Corp. POWER MOSFET Lead-Free Package D BVDSS 30V Low Conductance Loss RDS(ON) 4.7m Low Profile ( ... See More ⇒
