HYG045N03LA1C1 Specs and Replacement

Type Designator: HYG045N03LA1C1

Type of Transistor: MOSFET

Type of Control Channel: N-Channel

Absolute Maximum Ratings

Pd ⓘ - Maximum Power Dissipation: 23 W

|Vds|ⓘ - Maximum Drain-Source Voltage: 30 V

|Vgs|ⓘ - Maximum Gate-Source Voltage: 20 V

|Id| ⓘ - Maximum Drain Current: 50 A

Tj ⓘ - Maximum Junction Temperature: 175 °C

Electrical Characteristics

tr ⓘ - Rise Time: 19 nS

Cossⓘ - Output Capacitance: 273 pF

RDSonⓘ - Maximum Drain-Source On-State Resistance: 0.0048 Ohm

Package: DFN3X3-8L

HYG045N03LA1C1 substitution

- MOSFET ⓘ Cross-Reference Search



HYG045N03LA1C1 datasheet

 ..1. Size:1340K  1
 hyg045n03la1c1.pdf pdf_icon

HYG045N03LA1C1

HYG045N03LA1C1 N-Channel Enhancement Mode MOSFET Feature Pin Description 30V/50A RDS(ON)=3.9 m (typ.) @VGS = 10V RDS(ON)=5.2 m (typ.) @VGS = 4.5V 100% Avalanche Tested Reliable and Rugged Halogen Free and Green Devices Available Pin1 (RoHS Compliant) Applications Switching Application Battery Protection Single N-Channel MOSFET Ordering and Marking Info... See More ⇒

 1.1. Size:1346K  1
 hyg045n03la1c2.pdf pdf_icon

HYG045N03LA1C1

HYG045N03LA1C2 Single N-Channel Enhancement Mode MOSFET Feature Pin Description 30V/78A D D D D D D D D RDS(ON)= 3.6 m (typ.) @VGS = 10V RDS(ON)= 4.8 m (typ.) @VGS = 4.5V 100% Avalanche Tested Reliable and Rugged Halogen- Free Devices Available G S S S S S S G PDFN8L(5x6) Applications Load Switch Lithium battery protect board Single N-Channel MOSFET O... See More ⇒

 1.2. Size:1346K  hymexa
 hyg045n03la1c2.pdf pdf_icon

HYG045N03LA1C1

HYG045N03LA1C2 Single N-Channel Enhancement Mode MOSFET Feature Pin Description 30V/78A D D D D D D D D RDS(ON)= 3.6 m (typ.) @VGS = 10V RDS(ON)= 4.8 m (typ.) @VGS = 4.5V 100% Avalanche Tested Reliable and Rugged Halogen- Free Devices Available G S S S S S S G PDFN8L(5x6) Applications Load Switch Lithium battery protect board Single N-Channel MOSFET O... See More ⇒

 9.1. Size:863K  1
 hyg042n10ns1p hyg042n10ns1b.pdf pdf_icon

HYG045N03LA1C1

HYG042N10NS1P/B N-Channel Enhancement Mode MOSFET Feature Pin Description 100V/160A RDS(ON)=3.5m (typ.) @ VGS = 10V 100% Avalanche Tested Reliable and Rugged Lead-Free and Green Devices Available (RoHS Compliant) TO-220FB-3L TO-263-2L Applications Power Switching application DC-DC Converters N-Channel MOSFET Ordering and Marking Information ... See More ⇒

SHOW MORE
