HM40N20 MOSFET - описание производителя. Даташиты. Основные параметры и характеристики. Поиск аналога. Справочник
Наименование прибора: HM40N20
Тип транзистора: MOSFET
Полярность: N
Максимальная рассеиваемая мощность (Pd): 220 W
Предельно допустимое напряжение сток-исток |Uds|: 200 V
Предельно допустимое напряжение затвор-исток |Ugs|: 20 V
Пороговое напряжение включения |Ugs(th)|: 4 V
Максимально допустимый постоянный ток стока |Id|: 40 A
Максимальная температура канала (Tj): 175 °C
Общий заряд затвора (Qg): 163 nC
Время нарастания (tr): 24 ns
Выходная емкость (Cd): 290 pf
Сопротивление сток-исток открытого транзистора (Rds): 0.041 Ohm
Тип корпуса: TO220
HM40N20 Datasheet (PDF)
..1. hm40n20.pdf
Size:512K _cn_hmsemi
HM40N20N-Channel Enhancement Mode Power MOSFET Description The HM40N20 uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications. General Features VDS =200V,ID =40A RDS(ON)
0.1. hm40n20d.pdf Size:599K _cn_hmsemi
HM40N20DN-Channel Enhancement Mode Power MOSFET Description The HM40N20D uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications. General Features VDS =200V,ID =40A RDS(ON)
9.1. hm40n10k.pdf Size:534K _cn_hmsemi
N-Channel Enhancement Mode Power MOSFET Description The uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications. General Features VDS = 100V,ID =40A RDS(ON)
9.2. hm40n06d.pdf Size:701K _cn_hmsemi
HM40N06DN-Channel Enhancement Mode Power MOSFET Description The HM40N06D uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications. General Features VDS =60V,ID =40A RDS(ON)
9.3. hm40n10.pdf Size:798K _cn_hmsemi
HM40N10 N-Channel Enhancement Mode Power MOSFET Description The HM40N10 uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications. General Features VDS = 100V,ID =40A RDS(ON)
9.4. hm40n04k.pdf Size:1067K _cn_hmsemi
HM40N04KN-Channel Enhancement Mode Power MOSFET DESCRIPTION The HM40N04K uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications. GENERAL FEATURES VDS =40V,ID =40A RDS(ON)
9.5. hm40n15k.pdf Size:511K _cn_hmsemi
HM40N15K N-Channel Enhancement Mode Power MOSFET Description The HM40N15K uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications. General Features VDS =150V,ID =40A RDS(ON)
9.6. hm40n15ka.pdf Size:608K _cn_hmsemi
N-Channel Enhancement Mode Power MOSFET Description The uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications. General Features VDS =150V,ID =40A RDS(ON)
9.7. hm40n04d.pdf Size:949K _cn_hmsemi
HM40N04DN-Channel Enhancement Mode Power MOSFET Description The HM40N04D uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications. General Features VDS =40V,ID =40A RDS(ON)
9.8. hm40n10ka.pdf Size:608K _cn_hmsemi
HM40N10KAN-Channel Enhancement Mode Power MOSFET Description The HM40N10KA uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications. General Features VDS = 100V,ID =40A RDS(ON)
