D150 datasheet, аналоги, основные параметры
Наименование производителя: D150 📄📄
Тип материала: Si
Полярность: NPN
Предельные значения
Максимальная рассеиваемая мощность (Pc): 0.5 W
Макcимально допустимое напряжение коллектор-база (Ucb): 35 V
Макcимально допустимое напряжение коллектор-эмиттер (Uce): 30 V
Макcимально допустимое напряжение эмиттер-база (Ueb): 1 V
Макcимальный постоянный ток коллектора (Ic): 1 A
Предельная температура PN-перехода (Tj): 175 °C
Электрические характеристики
Граничная частота коэффициента передачи тока (ft): 80 MHz
Статический коэффициент передачи тока (hFE): 50
Корпус транзистора: TO106
📄📄 Копировать
