2N7007 MOSFET. Datasheet pdf. Equivalent
Type Designator: 2N7007
Type of Transistor: MOSFET
Type of Control Channel: N -Channel
Pdⓘ - Maximum Power Dissipation: 1 W
|Vds|ⓘ - Maximum Drain-Source Voltage: 240 V
|Vgs|ⓘ - Maximum Gate-Source Voltage: 30 V
|Vgs(th)|ⓘ - Maximum Gate-Threshold Voltage: 2.5 V
|Id|ⓘ - Maximum Drain Current: 0.065 A
Tjⓘ - Maximum Junction Temperature: 125 °C
tonⓘ - Turn-on Time: 30 nS
Cossⓘ - Output Capacitance: 15(max) pF
Rdsⓘ - Maximum Drain-Source On-State Resistance: 45 Ohm
Package: TO92
